The AGT-DM13C is a compact and versatile 1.3-ton mini excavator designed for various excavation tasks.
Technical Data:
Engine:
- Brand: Briggs & Stratton (B&S)
- Model: 13.5 HP
- Power Output: 9.8 kW
- Maximum Speed: 3,600 RPM
- Cylinders: 1
- Cooling Method: Fan cooling
- Engine Oil Capacity: 1.1 liters
- Fuel Type: Gasoline
- Fuel Grade: 92#
- Theoretical Fuel Consumption: 0.5-1.2 liters per hour
Performance:
- Operating Weight: 2,150 lbs (975 kg)
- Maximum Digging Depth: 1,650 mm
- Maximum Digging Height: 2,400 mm
- Maximum Digging Radius: 3,080 mm
- Maximum Climbing Ability: 30°
Hydraulic System:
- Main Pump Type/Model: Gear pump/06
- Main Pump Brand: Tianjin Xingzou
- Rated Set Pressure: 16 MPa
- Maximum Flow Rate of Main Pump: 21.6 liters per minute
- Multi-way Valve: 8 multi-way valves
- Multi-way Valve Brand: Bei Fang
Dimensions:
- Overall Length: 2,738 mm
- Overall Width: 935 mm
- Overall Height: 2,209 mm
- Bulldozer Width/Height: 907 mm / 210 mm
Undercarriage:
- Track Type: 7-inch rubber tracks
Additional Features:
- Cabin: Enclosed cab (no air conditioning)
- Boom: Articulating/swing boom with a 30° angle
- Attachments: Hydraulic thumb installed, 13-inch digging bucket, push blade
- Auxiliary Hydraulics: Yes
Specific Data:
| Basic Performance Parameters |
Working Weight (kg) | 940 |
| Bucket Capacity (m³) | 0.03 | |
| Travel Speed Low/High Speed (km/h) | 0-0.2 | |
| Climbing Ability (%) | 30 | |
| Maximum Digging Height (mm) | 2,795 | |
| Maximum Unloading Height (mm) | 1,863 | |
| Maximum Digging Depth (mm) | 1,684 | |
| Max. Digging Radius (mm) | 3,112 | |
| Side Swing | √ | |
| Side Swing Angle (L/R) | 30° | |
| Undercarriage Expansion | × | |
| Body | Overall Length (mm) | 2,738 |
| Overall Width (mm) | 935 | |
| Overall Height (mm) | 2,209 | |
| Bulldozer Width/Height | 907/210 | |
| Engine | Engine Brand | B&S |
| Engine Model | 13.5HP | |
| Max. Power (Kw) | 9.8 | |
| Max. Speed (rpm) | 3,600 | |
| Cylinders | 1 | |
| Cooling Method | Fan Cooling | |
| Engine Oil Change Quantity (L) | 1.1 | |
| Fuel Type | Gasoline | |
| Fuel Grade | 92# | |
| Theoretical Fuel Consumption (L/h) | 0.5-1.2 | |
| Hydraulic system |
Main Pump Type/Model | Gear Pumps/06 |
| Main Pump Brand | (Tianjin Xingzou) | |
| Rated Set Pressure (Mpa) | 16 | |
| Maximum Flow Rate of Main Pump (L/min) | 21.6 | |
| Multi-way Valve | 8 Multi-way Valves | |
| Brand of Multi-way Valve | (Bei Fang) | |
| Rated Set Pressure (Mpa) | 16 | |
| Hydraulic Linear Motor Type | BM6-310 | |
| Linear Motor Brand | (Li Yuan) | |
| Hydraulic Servo Motor Type | BM2-250 | |
| Excavator tracks | ▲-Rubber (Bandwidth*Pitch*Number of Sections) | 180*72*37 |
| Configuration | Cab | √ |
| Roof | × | |
| Handrail | × | |
| Thumb Clip | √ | |
| Counterweight | × | |
| Tensioning Forms | Mechanical Tensioning | |
| Air Conditioning | × | |
| Fuel tank | Fuel Tank (L) | 6.6 |
| Hydraulic Oil Tan (L) | 18 |
