AGT-KRW232 1.25-Ton 33 HP Mini Skid Steer With RATO Engine

AGT-KRW232 1.25-Ton 33 HP Mini Skid Steer With RATO Engine

$13,000.00 - $13,000.00
$13,000.00
$13,000.00 - $13,000.00
$13,000.00

Fast, Free shipping

1-Year Warranty

Lifetime Tech Support

AGT KRW232 1.25 Ton Mini Skid Steer Loader – RATO Engine | Compact Utility Machine

The KRW232 Mini Skid Steer Loader is a compact, high-performance machine built for tough jobs on farms, construction sites, and industrial yards. With a 1,100 kg operating weight and 380 kg lifting capacity, it offers powerful performance in tight spaces.

Powered by a 33 HP air-cooled RATO gasoline engine, the KRW232 features a high-efficiency hydraulic system with a 70 L/min flow rate for fast cycle times and smooth operation. Its narrow 900 mm width and 40° bucket discharge angle make it ideal for confined work areas and quick material handling.

Technical Data:

  • Operating Weight: 1100 kg
  • Bucket Capacity: 0.16 m³
  • Travel Speed: Up to 4.5 km/h
  • Max Lifting Force: 380 kg
  • Max Working Height: 3590 mm
  • Unloading Height: 1820 mm
  • Bucket Discharge Angle: 40°
  • Wheelbase: 801 mm

Engine:

  • Rato, Air-cooled
  • Max Horsepower: 33 HP.
  • Fuel Type: 92# Gasoline
  • Fuel Tank Capacity: 40 L
  • Theoretical Fuel Consumption: 10 L/h
  • Hydraulic Oil Tank: 40 L

Hydraulics:

  • Main Pump: PGP532B62
  • Max Flow Rate: 70 L/min

Dimensions:

  • Overall Length (with bucket): 2580 mm
  • Overall Length (without bucket): 1945 mm
  • Overall Width: 900 mm
  • Overall Height: 1820 mm
  • Tires: 570*16

Customer Reviews

Based on 1 review
0%
(0)
0%
(0)
100%
(1)
0%
(0)
0%
(0)
M
Mike Mac
Good for the price but...

Good for the price but has no hydraulic fluid control. Very jerky last minute action. no Quality control as far as electrical wiring and the littles things are ignored. No information given...come on somebody has to have information or a manual on this thing! Have fun doing an oil change. The wheels, lets talk about the wheels. What do they expect to get done on those skinny wheels but good solid tires but too skinny. Beefier tires would improve sales and the excavator capabilities by 25%. Where is the parts information. Business Can't survive without parts to back up thier equipment andvthe sad thing is they are building these so that means they have parts!...
