Technical Data：

Basic Performance Parameters

Working Weight(kg): 900

Bucket capacity(m³): 0.03

Travel speed low/high speed(Km/h): 0-1.8

Climbing ability(%): 11

A:Maximum Digging Height(mm): 2900

B:Maximum Unloading Height(mm): 2100

E:Max. digging radius(mm): 3250

F: Minimum turning radius(mm): 1470

G: Tail minimum turning radius(mm): 800

H: Maximum lifting height of bulldozer(mm): 190

I: Maximum digging height of bulldozer(mm): 190

Side Swing: YES

Equipment Body

J:Overall Length(mm): 3240

K:Overall Width(mm): 990

L:Overall Height(mm): 2200

M: Wheelbase(mm): 930

N: Track Gauge(mm): 810

Bulldozer Width/Height: 950/235

Engine

Engine Brand: B&S

Maximum power(HP): 13.5

Cooling method: Fan cooling

Fuel Type: Gasoline

Hydraulic system

Rated set pressure(Mpa): 16

Main pump maximum flow (L/min): 21.6
